Split Tray Sorter
)
)
)
)
)
)
Three Configurations, One Platform
The Split Tray Sorter is available in three configurations to match the scale and complexity of any operation. The Single Split Tray delivers between 3,000 and 17,000 trays per hour and features a concave tray surface that securely contains irregular, loose, or round items — from polybags and envelopes to pharmaceutical bottles and loose garments — without the need for additional packaging. The Dual Split Tray raises the bar significantly: its patented dual tray design allows each carrier to sort either two small items to two separate destinations simultaneously, or one larger item, effectively doubling throughput without increasing the sorter's footprint. It reaches up to 35,000 items per hour from a single induction point. For the highest-volume environments, the Quad Tilt Tray scales up to 69,000 trays per hour, offering the kind of capacity required by national postal operators and large-scale parcel hubs.
Patented Flat-Drop Technology
Unlike conventional bomb-bay sorters that angle items as they discharge, EuroSort's patented tray mechanism releases items completely flat into the destination chute or outbound carton. This flat-drop action keeps items stacked neatly, significantly reducing product damage and eliminating much of the manual re-handling typically required at pack-out. For CEP operators processing millions of items daily, this directly reduces error rates, re-work, and associated operational costs.
Industry-Leading Discharge Pitch
EuroSort's discharge pitch is up to 70% tighter than competing sortation technologies. In practical terms, this means operators can either fit significantly more sort destinations into the same floor space, or achieve the same number of destinations in a considerably smaller area. For e-commerce fulfilment centres handling a large number of delivery routes, carriers, or postal codes, this translates into more granular sortation, fewer secondary sort passes, and a leaner overall facility layout.
Built for the Full CEP and E-Commerce Product Mix
The Split Tray Sorter handles items up to 11 kg across a wide range of shapes and formats — polybags, padded mailers, envelopes, flatpacks, shoeboxes, and mixed cartons — without the need for pre-sorting or repackaging. Its concave tray design keeps even cylindrical or irregularly shaped items in place throughout the sort cycle, removing the traditional barrier between conveyable and non-conveyable goods. Manual induction is fully supported across all configurations, providing flexibility during peak periods or when automated induction is not required.
Low Noise, Low Maintenance
Operating at below 70 dB, the Split Tray Sorter is one of the quietest high-throughput sorters available — an important consideration for multi-shift operations and facilities with strict noise requirements. Its predominantly mechanical tray design minimises the number of components susceptible to wear, keeping maintenance requirements low and uptime high. The aluminium frame structure, largely assembled without welding, allows for straightforward expansion and reconfiguration as operational requirements evolve.
Designed for Omnichannel and Returns Processing
Beyond outbound parcel sortation, the Split Tray Sorter supports inbound processing, returns handling, and omnichannel fulfilment flows on a single system. For e-commerce operators managing high return volumes alongside outbound despatch, the ability to consolidate these flows on one sorter reduces both capital investment and operational complexity.
With over 500 installations across more than 40 countries, the EuroSort Split Tray Sorter is a proven, scalable solution trusted by some of the world's leading postal operators, parcel carriers, and e-commerce businesses — delivering the speed, accuracy, and flexibility that modern CEP logistics demands.
